DELL XPS 700 710 Tower Mainboard Motherboard YF432
product description
DELL XPS 700 710 Tower Mainboard Motherboard YF432
Genuine DELL Tower Mainboard
for XPS 700 and 710
Chipset:
nVidia nForce 590 SLI MCP (C19 Northbridge, MCP55 Southbridge)
Processor:
Intel Pentium 4
Intel Pentium D
Intel Core 2 Duo
Memory:
4 DIMM slots; Unbuffered Dual Channel 533MHz and 667MHz DDR2 SDRAM, supporting up to 8GB RAM
Video:
PCI Express
Audio:
HDA 7.1 Channel
Standard I/O Ports:
10 - USB 2.0 (2 front, 6 rear, 2 internal)
2 - IEEE 1394 Firewire (1 front, 1 back)
1 - RJ-45
2 - PS2
1 - Serial
2 - Line-in (stereo, microphone)
5 - Line-out
Expansion Capabilities:
1 - IDE Drive connector (40-pin)
6 - SATA connectors (7-pin)
1 - Floppy Drive connector (34-pin)
3 - Fan connectors (5-pin)
3 - PCI Slots (120-pin)
1 - PCIe x1 Slot (36-pin)
1 - PCIe x8 Slot (98-pin)
2 - PCIe x16 Slots (164-pin)
Partnumbers: YF432, 0YF432
Condition: refurbished
